Driver position

Left Hand

Driving type

6*4

Wheelbase/(mm)

3775+1400

Max. Speed/(km/h)

100km/h

Engine

Brand

WEICHAI

Model

WP12.430E201

Emission Standard

EURO II

Rated output power/（PS）

316KW/430HP

Displacement(L)

11.596L

Transmission

Brand

FAST

Model

12JSDX220T-B-

Front axle

Brand

HANDE

Model

MAN 7.5T

Rear axle

Brand

HANDE

Model

16T MAN Double stage widened bridgeSpeed ratio: 4.266

Clutch

￠430 diaphragm clutch

Steering

ZF technology

Frame

850×300（8+5）

Suspension

Front and rear multi leaf springs, four main plates+four saddle bolts

Fuel tank

600L Aluminum alloy

Wheels and tires

315/80R22.5

Brakes

Running brake:Dual circuit compressed air brake

Parking brake:Air discharging with spring control

Auxiliary brake:Engine exhaust brake

Cabin

H3000 extended flat top cab without top air deflector, air master seat, four point hydraulic suspension,

pole type rearview mirror, single refrigeration air conditioning, electric window rocking machine, manual

flipping, metal bumper with light protection net, three-level boarding pedal, oil bath air filter, ordinary

exhaust, water tank protection grille, ordinary 90 saddle, split type mudguard, tail light protection grille,

165Ah maintenance free battery, sunshade lighting fixtures all in white, 2 hazard warning lights,

SHACMAN logo, full English logo, additional ordinary coarse filter, iron air storage cylinder, reverse buzzer,

telescopic shaft control, battery box anti-theft, fuel tank cap anti-theft, side mounted spare spare spare

parts anti-theft tire frame
